Información detallada
Material:	Cuadro de aluminio + panel de vidrio	La transparencia:	Está bien.
Personalizable:	Tamaño, accesorios	Precio competitivo:	- ¿ Qué?
espesor del vidrio:	5 mm, 8 mm, 10 mm, 12 mm, sólido	Tipo de vidrio:	vidrio templado fuerte
Material del marco:	de aluminio	Ventaja:	Precio competitivo, buen servicio, alta profesionalidad, garantía de calidad

Descripción de producto

Double-Glass Partition System Specifications Advanced Acoustics High Configuration 0

Glawall Double-Glass Partition System – Technical Specifications
Premium Architectural Glass Walls for Modern Spaces
Designed for offices, conference rooms, and high-traffic areas requiring transparency + superior acoustics.

1. Core Specifications

Parameter Specification

Glass Construction Double-layer tempered safety glass (5+5mm or 12+12mm)

Wall Thickness 79mm / 90mm / 108mm systems available

Max Height <3,200mm (custom heights with structural reinforcement)

Frame Profile Slim 35mm/40mm aluminum or stainless steel

Glass Connection Near-invisible joints: acrylic tape / metal strips / crystal beading

Acoustic Performance Rw 40-48dB (upgradable to 50dB with laminated glass)

Sound Absorption >0.9 NRC (optional perforated metal or 3D fiber panels)

Double-Glass Partition System Specifications Advanced Acoustics High Configuration 1

2. Key Features

✔ Seamless Aesthetic	Frameless glass-to-glass connections (1-3mm visible joint)
	Ultra-slim 35-40mm profiles for minimalist elegance
✔ Advanced Acoustics	12+12mm glass + air gap for STC 48 performance
	Optional sound-absorbing cores (3D polyester fiber)
✔ Privacy & Light Control	Integrated 16mm/25mm aluminum louvers (manual or motorized)
	Switchable PDLC glass (instant privacy)
✔ Structural Innovation	Height-adjustable frames (±15mm tolerance compensation)
	Seismic-compliant designs available

Double-Glass Partition System Specifications Advanced Acoustics High Configuration 2

3. Configuration Options

A. System Types	Model Best For	79mm Frame (5+5mm) Budget-friendly divisions
		108mm Panoramic (12+12mm) Premium executive offices
		90mm Acoustic (5+5mm) Meeting rooms & call centers
B. Door Solutions	Glass pivot/sliding doors (frameless or aluminum-framed)
	Solid wood/steel doors (fire-rated options)
	Hybrid glass+panel designs

4. Performance Advantages

Thermal Efficiency – Low-E coatings reduce HVAC loads
Safety – Tempered glass breaks safely into blunt pieces
Hygiene – Non-porous, hospital-grade cleanability
Reconfigurable – Demountable for space changes

Double-Glass Partition System Specifications Advanced Acoustics High Configuration 3

5. Ideal Applications

Corporate HQs	(open-plan offices, boardrooms)
Healthcare	(private consultation rooms)
Luxury retail	(display partitions)
Education	(quiet study zones)
Technical Comparison	Glass Thickness
	Glass Type Weight (kg/m²) Soundproofing Best Use
	5+5mm 24 STC 40 General office spaces
	12+12mm 56 STC 48 High-noise environments

Why Professionals Choose This System?

Precision German track systems (300,000+ cycle durability)
BIM-compatible for seamless project integration
15-year structural warranty
"Where architectural vision meets acoustic science."

Double-Glass Partition System Specifications Advanced Acoustics High Configuration 4

The beautiful design is particularly suitable for offices, corridors, around the core tube, conference rooms, exhibition halls and other areas.

Basic parameters:
Panel thickness:	double-layer 12+12mm, 5+5mm tempered safety glass;
Wall thickness	3mm
Glass wall height	<3200mm
Frame profile height	40mm, 35mm;
Glass connection	transparent acrylic tape, metal ultra-narrow strip, crystal bead;
Sound insulation parameters	40-48dB;
Sound absorption coefficient	>0.9 (perforated metal sound-absorbing panels, 3D polyester fiber sound-absorbing panels can be configured)
Optional models	79mm frame double glass 5+5mm glass, 79mm frame panoramic double glass 12+12mm glass, 90mm frame double glass 5+5mm glass, 108mm frame single glass 5+5mm glass, 108mm frame double glass panoramic 12+12mm glass
Door type	single glass door, framed single and double glass door, wood grain/solid color steel door (multiple color cards available), double glass shutter glass door, double glass hidden frame door, wooden door, sliding door.
Product features	Fully transparent double-layer glass structure, frameless connection between glass panels, fun and simple lines, 3mm frame, height adjustment function, extraordinary sound insulation performance to meet the ultimate quiet requirements.

Double-Glass Partition System Specifications Advanced Acoustics High Configuration 5

[Contact our engineers for custom configurations]

Glawall – Redefining spatial boundaries with light and innovation.

Double-Glass Partition System Specifications Advanced Acoustics High Configuration 6

etiqueta:

Datos del producto:
Lugar de origen:	China.
Nombre de la marca:	Glawall
Certificación:	SGS, ISO 9001,UL, CE
Número de modelo:	Pared divisoria de aluminio personalizada con doble vidrio
Pago y Envío Términos:
Cantidad de orden mínima:	10 metros cuadrados
Precio:	US$80.00 10 - 99 square meters
Detalles de empaquetado:	Paquete de madera
Tiempo de entrega:	2-3 semanas
Condiciones de pago:	En el caso de las empresas que no cumplen con los requisitos de la presente Directiva, el importe de
Capacidad de la fuente:	3000 metros cuadrados por mes
